Senior Thesis Proposal Overview

Redesign- The redesign proposed includes changing the water-to-air heat pump system to a water-to-water system utilizing radiant floor heating and cooling, redesigning the hip roof trusses to a simpler gable roof system allowing for the design of a BIPV system. A solar shingle array will be used to offset the energy used by the mechanical system. Also a solar thermal collection system will be installed to supply domestic hot water.

Breadth- The breadth of the project will be an analysis of both the structural and construction impacts of the proposed redesign. This will include a redesign of the slab floor to house the radiant floor system and a redesign of the truss roofing system for the structural breadth. For the construction breadth an analysis of the cost, scheduling and constructablitiy will be performed.

IP- The solar thermal collection system will rely on Dr. Treado's 596, Solar Thermal Energy Systems and Design, course information. This will include the design of the collection system sized to supply all of The Sunshine Elementary Schools' domestic hot water demand.

n

Initial Proposal- to Download Click Here

Revision- The revised Proposal includes an updated to the breadth work of the project. Added detail to the intend work has been included better clarifing the goals to be reached.

n

Revised Proposal- to Download Click Here
