Technical Assignment I is an analysis of The Sunshine Elementary Schools compliance with ASHRAE Standards. An analysis of Standards 62.1 and 90.1 has been performed. The design of the building has proved to be above and beyond the compliance of these standards.

Technical Assignment One- to open click here

Technical Assignment II is a building and Plant Energy Analysis. The analysis included building of an energy in Trane TRACE 700 and compairing results will an eQuest model given by the mechanical designer of the project.

techII image

Technical Assignment Two- to open click here

Technical Assignment III is an analysis of the designed mechanical systems exsisting conditions. The evaluation included system operations and schematics of the system along with a LEED analysis focusing on the energy and Atmosphere credits along with the Indoor Environmental Quality credits.

n

Technical Assignment Three- to open click here
