This thesis focuses on redesigning the lateral system using concrete moment frames instead of the current concrete shear walls. The existing structure uses 157 mph design wind speed, far surpassing the minimum code level. This lateral analysis studies if concrete moment frames are feasible for 110 mph, the minimum design wind speed for Orlando, in addition to the 157 mph case.

Additionally, a flat plate system is considered rather than the current flat slab. Flate plate designs eliminate drop panels and column capitals, thus producing a more cost effective slab system with a reduction of form work. The slab-column connections require detailed analyses to determine if the connection can withstand the moment transfer and applied shear.

Daylighting and Building Enclosure Study

In addition to the lateral and floor system redesign, two breadth topics are explored. One topic is a daylighting study of the sun management of a south facing façade. This determines if the current louvers can adequately control the sun. Additionally, an alternative interior sun control system is presented. The second breadth topic examines the structural system of the façade, for both constructability and maintainability. An aluminum mullion design is presented as an alternate to the current silicone structural sealant.

Click here to view a pdf of the executive summary

Click here to view a pdf of the final report
